IoT Gateway M1
Value Line, Affordable
Single-core Arm
Cortex-A8
EdgeLock
Secure Enclave
Single 10/100Mbps
Ethernet
AI & ML
Capabilities
Product Overview
Calixto’s IoT Gateway is a rugged, intelligent connectivity platform designed to bridge edge devices with cloud infrastructure in industrial and commercial environments. Built on a reliable ARM-based architecture, the gateway supports a wide range of wired and wireless interfaces including Ethernet, Wi-Fi, LTE, and optional LoRa or BLE for flexible deployment across diverse IoT ecosystems. With built-in security features, edge analytics capability, and support for multiple protocols like MQTT, Modbus, and OPC UA, it ensures seamless and secure data acquisition, processing, and transmission. Its compact industrial-grade design with wide temperature support and DIN rail mounting makes it ideal for remote monitoring, smart energy, predictive maintenance, and automation applications. Calixto’s IoT Gateway empowers edge-to-cloud integration with scalable performance, reliable operation, and simplified deployment.
Features
Optimized Performance
Unparalleled performance for responsive embedded computing, real-time control, and rich user interfaces while maintaining power efficiency.
Reliable, 200 PIN SODIMM Connector
Ensures robust mechanical integrity, streamlined manufacturing, and enhanced reliability in rugged industrial applications.
Industrial-Grade Reliability
Engineered for exceptional reliability and long-term operation in demanding industrial environments.
Rich I/O and Connectivity
Comprehensive I/O and industrial connectivity options enable seamless integration with a wide range of peripherals and field interfaces.
Specifications
Processor:
Processor: AM335x
Architecture: Arm Cortex-A8
Frequency: 1GHz
Memory:
RAM: 256/512/1024MB DDR3L
eMMC: 4/8/16GB
NOR FLASH: 8MB
Peripheral List:
6x UART
2x SPI
2x CAN
3x I2C
2x USB 2.0 OTG
2x MMC/SD
8x ADC Channels
3x eHRPWM
3x eQEP
Connectivity:
10/100Mbps Ethernets (PHY on board)
Multimedia:
24-bit RGB Parallel Display
Touch Screen Controller
2x McASP
Miscellaneous:
RTC
JTAG
Cryptography
Device Identity
