i.MX93 VERSA SOM EVB
- Energy Efficient
- Secure
Dual Core Arm Cortex-A55
MIPI DSI, LVDS
Power Efficient
CAN, RS485, USB Host, USB OTG
Product Overview
The i.MX93 VERSA SoM Evaluation Board is a feature-rich platform designed to accelerate the development and evaluation of applications built on the i.MX93 VERSA SoM. It integrates the NXP i.MX93 processor with a 1.7GHz Dual Cortex™-A55 and a 250MHz Cortex-M33 real-time co-processor, along with an NPU for efficient AI processing at the edge. This versatile board provides extensive connectivity and interface options, including CAN, RS485, Gigabit Ethernet, USB, MIPI and LVDS display, MIPI Camera, and IOs
Features
High-Performance Computing
Engineered for high-performance compute, AI acceleration, and advanced vision processing.
Optimized for Al and Vision
Enables real-time machine learning and inferencing for applications such as predictive maintenance, and autonomous edge devices.
Industrial Reliability
Designed and manufactured for high reliability and longevity in harsh, demanding environments.
Power Efficient
Combines advanced processing with energy efficiency to meet the demands of modern industrial and IoT deployments.
Specifications
Processor:
Processor: i.MX93
Core: Dual Core Arm Cortex-A55@1.7GHz
Architecture: Arm64
MCU Core: Arm Cortex-M33@
Memory:
RAM: 2GB LPDDR4X
eMMC: 8Gb
Peripheral List:
USB Host
USB OTG
RS485
CAN-FD
RTC + Backup
SD Card
Expansion Connector – GPIOs/PWM/UART/SPI/I2C/SAI/Parallel RGB Display
Connectivity:
Gigabit Ethernet
Multimedia:
MIPI CSI
MIPI DSI
LVDS
Miscellaneous:
JTAG
Debug UARTs – A55 and M33
Tamper Protection
Design Resources
- Hardware user manual
Software Releases
- Yocto Project: Scarthgap
- Linux Kernel: 6.6.2
- Debian: Bookworm
